ℹPlug & Play — no structural modification required. Suitable for residential and short-term installs.
Step 1 — Site Assessment
Identify a standard 220V/110V outlet within 1.5m of the target diffusion zone. Confirm floor is level and ambient temperature is between 15–35°C.
Step 2 — Unit Placement
Position HELI unit on a flat surface or wall-bracket at 1.8–2.1m height for optimal mist dispersion. Keep 30cm clearance on all sides.
Step 3 — Cartridge Install
Release the locking clip on the cartridge bay (bottom panel). Insert cartridge with label facing outward until you hear a click. Close and secure clip.
Step 4 — Network Pair
Power on the unit. Connect to the temporary "HELI-SETUP" Wi-Fi network and follow the in-app pairing flow. Device will appear in portal within 60 seconds.
Step 5 — Verify & Log
Confirm sensor readings in the portal (temp, humidity, solution level). Log the install via the Calendar tab, selecting "Install — Non-Invasive".
⚠Hardwired installation — requires licensed electrician and access panel. For permanent commercial/hospitality installs only.
Step 1 — Permit & Safety
Obtain necessary building permits. Confirm power is isolated at the breaker. Coordinate with a licensed electrician for all wiring work.
Step 2 — HVAC Integration (Optional)
For whole-building distribution, mount the cartridge housing inside the HVAC plenum box. Connect stainless tubing to the client-facing diffuser head. Requires HVAC technician sign-off.
Step 3 — Cartridge Housing Mount
Anchor the cartridge utility housing to wall studs in the utility/plant room using M8 bolts. Run tubing (max 6m) through conduit to the diffuser head location.
Step 4 — Hardwire Power
Wire the unit to a dedicated 16A circuit. Ensure an isolator switch is accessible within 1m of the unit. All wiring must comply with local electrical code.
Step 5 — Network & Commissioning
Connect the control module to the site mesh/ethernet. Complete commissioning checklist. Verify all sensor data in the portal before handover. Log the install via the Calendar tab.
Cartridge Refill (Invasive)
Power down at isolator. Release locking clip, slide out spent cartridge, insert fresh cartridge until click. Restore power. Log refill via Calendar tab.
